NEW! Real-time respirable dust exposure monitoring.
Ultra light & wearable, built for industrial environments.
NEW! Real-time respirable dust exposure monitoring.
Ultra light & wearable, built for industrial environments.
Engineered for easy real-time monitoring of dust concentrations.
Ultra light and wearable at 5.25oz (149g), it’s the lightest monitor on the market – but built with rugged over-molding for commercial and industrial settings such as construction sites and workshops. The Gilian Dustlight’s laser photometry measures the fraction of inhalable dust PM10, respirable dust PM4, as well as PM2.5 and PM1, providing an assessment of particulate matter concentration.
Compliments gravimetric sampling for OSHA compliance: provides immediate feedback on air quality using a simple traffic light system, audible warnings, and digital display, allowing remediation before standard gravimetric sampling and lab analysis – saving time and lab costs!
(click image to view larger)
Note: additional sampling cycles may be needed to meet the new OSHA standard.
Real-Time Monitoring
Provides instant feedback on air quality, allowing for immediate awareness of dust levels.
Bright Traffic Light System
Offers an intuitive color-coded warning system (green, yellow, red) for quick assessment of dust concentrations.
Modular Mounting (Klick Fast system)
Versatile attachment options for clothing, belts, and other accessories for comfortable, secure wear.
Data Logging & Analysis
Records measured dust concentrations for trend analysis and allows for data export via the mobile app.
Rugged Over-Molding Design
Built to withstand demanding industrial environments.
Intelligent Maintenance
Features a system for calculating maintenance intervals and provides notifications.
Configurable Settings
Allows users to adjust warning thresholds, operating modes, and other parameters via the mobile app.
Wireless Connectivity
Enables seamless connection to the mobile app for data visualization, settings adjustments, and firmware updates.
(click image to view larger)
(click image to view larger)
Scan or Click to Download App:
| Part Number | Description | |||||
| 810-2301-01-R | Gilian Dustlight Starter Kit | |||||
| Single Device, Magnetic USB Charging Cord, Calibration Certificate | ||||||
| 910-2306-US-R | 6 Pack Kit w/US Cord | |||||
| 910-2306-UK-R | 6 Pack Kit w/UK Cord | |||||
| 910-2306-EU-R | 6 Pack Kit w/EU Cord | |||||
| 6 Devices, Carrying Case, Magnetic USB Charging Cords, Charging Hub, Calibration Certificates | ||||||
| Part Number | Description | Image |
| 811-2301-02 | Waterproof Case for 2 Gilian Dustlights |
|
| 811-2301-06 | Waterproof Case for 6 Gilian Dustlights |
|
| 811-2304-01 | Klick Fast Chest Strap |
|
| 811-2304-02 | Klick Fast Wrist/Arm Bracelet |
|
| 811-2304-03 | Klick Fast Clothing Fastener |
|
| 811-2304-04 | Klick Fast Belt Loop |
|
| 811-2303-01 | Klick Fast On-Device Replacement Clip |
|
| 811-2305-01 | Magnetic Charging Cable |
|
| 811-2307-US | 6-Port USB Charging Hub, US Cord |
|
| 811-2307-EU | 6-Port USB Charging Hub, EU Cord | |
| 811-2307-UK | 6-Port USB Charging Hub, UK Cord | |
| 811-2308-01 | Replacement Front Grill, 2-Pack |
|
| 811-2309-01 | Charging Port Cover |
Reach out to Our Expert Team for Tailored Safety Solutions and Technical Guidance.
Dimensions
Width x Height x Depth
2.7 x 2.7 x 1.3 inches / 69 x 69 x 32.5 mm, without clip
Weight
5.25 oz / 149 g – The lightest Dust Monitor on the market!
Housing Material
Housing in ABS with protective layer in TPU
Battery Supply
Lithium-ion battery, 1700 mAh, runtime depends on operating mode and usage:
Continuous: up to 7 hours
Standard: up to 20 hours
Eco: up to 40 hours
Power Supply
Via enclosed USB cable with dust-protected magnetic coupling
Fastening
Modular Klick-Fast fastening system – attachment to belt clip, Velcro fastener/patches on clothing, cross-chest carrying strap, wrist strap, etc.
Storage Temperature
– 4° to 104°F / – 20° to 40°C
Operating Temperature Range
14° to 122°F / – 10° to 50°C
Operating Humidity Range
0 – 80 % RH
Alerting
LED display with good visibility, LCD color display, acoustic signal, app notifications
Limit Values
General respirable dust limit from TRGS 900 for red warning light (limit at 1250 μg/m³), yellow light at 10% of this limit. Dust limits can be configured via our free Dustlight app.
Measuring Method
Laser-based Photometry
Measuring Interval
Depending on the selected mode, from every 1 second to every 60 seconds. After start, needs 30 seconds to reach the first stable measured value.
Measuring Range
Concentration: 0 – 10 000 μg/m³
Particle sizes: 0.3-10 μm
Special Calibration
Accuracy report will be given (contact us for more info)
Accuracy for PM1 and PM2.5 *
0-100 μg/m³: ± 5 μg/m³ AND ± 5 %
100-5,000 μg/m³: ± 10 %
Accuracy for respirable dust PM4 and the PM10 fraction of inhalable dust *
0-100 μg/m³: ± 25 μg/m³
100-5,000 μg/m³: ± 25 %
Maintenance
Intelligent maintenance calculation depending on usage time and dust concentration, at least every 12 months
Sustainability
Repair-friendly design, at local Authorized Service Centers.
Production
Designed and manufactured in Germany.
Approvals
CE, UKCA, FCC, cTUVus
* The sensor accuracy was determined by an external institute using the “Grimm Model 11-D” measuring device and “Arizona A1” test dust
Disclaimer Notice:
All the information contained herein is believed to be accurate and is subject to change without notice. Users should independently evaluate the suitability of each product for their own applications.
The Gilian Dustlight is an innovative, mobile dust monitor specifically developed for trade, industry, and workplaces where large quantities of dust are generated. It is designed to reduce health risks associated with dust exposure and protect employees from airborne particles.
The Gilian Dustlight provides real-time monitoring of respirable dust concentrations using a three-color traffic light indicator (green, yellow, red) and a high-resolution display. It alerts employees when dust levels reach critical points, prompting the use of protective measures like masks or air extraction systems.
Every employee in dust-prone areas should wear a Gilian Dustlight on their body – in the breathing zone – using the enclosed clip or additional fastening accessories. This ensures constant monitoring and immediate alerts in dusty environments.
The Gilian Dustlight is designed to be user-friendly, with a single-button operation and an intuitive, language-neutral display that shows dust concentration levels clearly.
The Gilian Dustlight uses a traffic light system to indicate air quality:
GREEN Air quality is safe.
YELLOW Caution is advised; dust levels are approaching unsafe limits.
RED Dangerous dust concentrations; immediate action is needed.
No, the Gilian Dustlight is not a replacement for PPE like masks or dust extractors. It is a tool to monitor air quality and support risk assessments, ensuring appropriate use of PPE when necessary.
The Gilian Dustlight features a rechargeable battery that lasts up to 9 hours in continuous mode and up to 40 hours in eco mode. It can be fully charged in about 3 hours using the included magnetic USB cable.
The Gilian Dustlight is intended for indicative measurements and can help determine if additional gravimetric testing is necessary, potentially saving time and costs. However, it should not be solely relied upon for compliance with occupational exposure limits. It is not a replacement for gravimetric sampling.
The Gilian Dustlight has preloaded thresholds for Respirable Dust, based on the end users Regional/Country specific standards. These limits can be adjusted via the Gilian Dustlight app to fit specific workplace requirements.
The Gilian Dustlight is robust, shock-resistant, and designed for harsh working conditions, making it ideal for use in various industrial and trade environments where dust exposure is a concern. However, the Gilian Dustlight is not certified for hazardous areas where Intrinsically Safe equipment is required.
* * * * * * * * * * * * * * * * * *
